北京现代汽车4S店通风降温改造项目

【项目背景与挑战】

本项目位于我国南方重要城市——广州。广州地处亚热带海洋性季风气候区，夏季漫长且高温高湿，素有“火炉”之称，年平均气温高达22℃，7月至9月极端气温常突破35℃，且伴随高湿度。在这样的气候条件下，密闭或半封闭空间极易形成闷热难耐的环境，严重影响工作效率与人员体验。

放眼全国，汽车4S店作为城市服务业的重要窗口，遍布各大城市核心与郊区。它们不仅是汽车品牌的展示厅，更是保障车主日常出行安全、提供专业维保服务的技术中枢。然而，4S店的维保车间往往面临一个行业共性难题：建筑结构多为高大的彩钢棚或钢结构厂房，虽便于车辆进出，但隔热性能差，且需频繁开启大门通风，导致传统空调难以发挥效用。 在闷热的车间里，维保技工长时间高强度作业，极易导致中暑、疲劳，进而影响维修质量和生产效率。因此，如何为一线技工创造一个相对舒适的工作环境，同时兼顾接待区的客户体验，成为4S店运营者亟待解决的痛点。

【瑞峰方案：量身定制的移动式离心冷风机布置】

该4S店主体位于一大型彩钢棚建筑内，环境相对开放，仅客户接待休息区做了隔断与精装修。针对这一现状，瑞峰环保制冷的方案设计人员深入现场，综合考虑了广州高温高湿的气候特点、车间频繁进出车辆的开放式结构、以及维保技工需要在不同车辆间流动工作的作业模式，最终摒弃了传统固定式空调方案，创新性地采用了“移动离心式冷风机” 进行整体布局。

此方案的设计逻辑基于以下几点深度考量：

1、灵活应对流动工位： 维保技工的工作区域不固定，可能在车头、车尾或底盘下。移动式机型自带万向轮，可随时推至任意工位，实现“人走到哪，风跟到哪”的精准送风，避免了固定风口的浪费。

2、原理匹配开放空间： 在需要频繁开门通风的车间，传统空调无法保持冷气。而冷风机（也称环保空调、水冷风机）利用“水蒸发吸热”这一最自然的物理原理：当热空气穿过湿润的湿帘时，水分蒸发吸收空气中的热量，从而送出凉爽、湿润的洁净风。这种“正气压”送风不仅能有效降温（通常降温幅度可达4-10℃），还能保持空气流通，且完全不受开门开窗的影响。

3、大风量改善体感： 我们选用的离心式冷风机具备风压大、风量足的特点。即便在空间开阔、纵深较长的彩钢棚车间，也能实现远距离送风，形成有效的空气对流，迅速驱散车辆散发的热浪和漆料异味，让维保人员在闷热环境下也能感受到持续、强劲的凉爽，极大提升了工作舒适度和安全性。

【客户价值与社会效益】

项目实施后，车间环境得到了立竿见影的改善。技工们纷纷表示：“以前夏天干活像蒸桑拿，现在有了这个冷风机，整个后背都是凉的，干活也更有劲了。” 车主在休息区透过玻璃看到整洁有序、环境清凉的车间，也对4S店的管理水平给予了更高评价。

【案例延伸与瑞峰实力】

此次北京现代4S店的项目，虽然看似是单一的汽修厂通风布置，但其成功经验可广泛复制于各类相似场景。例如：各类机械加工厂房、物流仓储中心、大型展览馆、临时性活动篷房，甚至是户外餐饮大排档等。这些场所普遍存在空间高大开放、人员流动性强、难以安装传统空调的共性需求。

瑞峰环保制冷正是凭借对特殊空间、特殊使用场景的深刻理解，才具备了“量体裁衣”的综合设备选型能力与方案设计能力。 我们不仅提供设备，更提供基于环境数据分析与人体工学原理的“全场景舒适度解决方案”，致力于为每一位客户打造最适宜的工作与经营环境。

Beijing Hyundai 4S Store Ventilation and Cooling Renovation Project

Project Background and Challenges

This project is located in Guangzhou, an important city in southern China. Guangzhou is located in the subtropical maritime monsoon climate zone, with long and high temperature and humidity summers, known as the "furnace". The annual average temperature is as high as 22 ℃, and extreme temperatures from July to September often exceed 35 ℃, accompanied by high humidity. Under such climatic conditions, enclosed or semi enclosed spaces are prone to creating a stuffy and unbearable environment, seriously affecting work efficiency and personnel experience.

Looking at the whole country, automobile 4S stores, as important windows of urban service industry, are located in the core and suburbs of major cities. They are not only exhibition halls for car brands, but also technical hubs that ensure the daily safety of car owners and provide professional maintenance services. However, the maintenance workshops of 4S stores often face a common industry problem: the building structures are mostly tall color steel sheds or steel structure factories, which are easy for vehicles to enter and exit, but have poor insulation performance and require frequent opening of doors for ventilation, making it difficult for traditional air conditioning to function effectively. In the hot and humid workshop, maintenance technicians work at high intensity for long periods of time, which can easily lead to heatstroke and fatigue, thereby affecting the quality of maintenance and production efficiency. Therefore, how to create a relatively comfortable working environment for frontline technicians while also taking into account the customer experience in the reception area has become an urgent pain point for 4S store operators to solve.

Ruifeng Solution: Tailored Mobile Centrifugal Air Cooler Layout

The main body of the 4S store is located in a large color steel shed building, with a relatively open environment. Only the customer reception and rest area has been partitioned and finely decorated. In response to this situation, the design team of Ruifeng Environmental Protection Refrigeration went deep into the site and comprehensively considered the climate characteristics of high temperature and high humidity in Guangzhou, the open structure of frequent vehicle entry and exit in the workshop, and the operation mode of maintenance technicians needing to move between different vehicles. Finally, they abandoned the traditional fixed air conditioning scheme and innovatively adopted a "mobile centrifugal air cooler" for overall layout.

The design logic of this plan is based on the following in-depth considerations:

1. Flexible response to mobile workstations: The work area of maintenance technicians is not fixed and may be located at the front, rear, or under the chassis. The mobile model comes with universal wheels that can be pushed to any workstation at any time, achieving precise air supply wherever people go and avoiding the waste of fixed air vents.

2. Principle matching open space: In workshops that require frequent door opening for ventilation, traditional air conditioning cannot maintain air conditioning. And air coolers (also known as environmentally friendly air conditioners or water-cooled fans) use the most natural physical principle of "water evaporation absorbs heat": when hot air passes through a moist curtain, the moisture evaporates and absorbs the heat in the air, thereby sending out cool, moist clean air. This' positive pressure 'air supply not only effectively reduces temperature (usually by 4-10 ℃), but also maintains air circulation and is completely unaffected by opening doors and windows.

3. High air volume improves body sensation: The centrifugal air cooler we have chosen has the characteristics of high air pressure and sufficient air volume. Even in spacious and deep color steel shed workshops, long-distance air supply can be achieved, forming effective air convection, quickly dissipating the heat waves and paint odors emitted by vehicles, allowing maintenance personnel to feel sustained and strong coolness even in hot and humid environments, greatly improving work comfort and safety.

Customer Value and Social Benefits

After the implementation of the project, the workshop environment has seen immediate improvement. Technicians have expressed, "In the past, working in the summer was like taking a sauna, but now with this air cooler, the whole back is cool and the work is more energetic." Car owners saw the clean and orderly workshop with a cool environment through the glass in the rest area, and also gave a higher evaluation of the management level of the 4S store.

Case Extension and Ruifeng Strength

The project of Beijing Hyundai 4S dealership, although seemingly a single ventilation layout for auto repair shops, its successful experience can be widely replicated in various similar scenarios. For example, various mechanical processing plants, logistics and warehousing centers, large exhibition halls, temporary activity tents, and even outdoor catering stalls. These places generally have common needs such as high and open spaces, strong personnel mobility, and difficulty in installing traditional air conditioning.

Ruifeng Environmental Protection Refrigeration relies on a profound understanding of special spaces and usage scenarios to possess the comprehensive equipment selection and scheme design capabilities of "tailor-made". We not only provide equipment, but also offer a "full scenario comfort solution" based on environmental data analysis and ergonomic principles, committed to creating the most suitable working and business environment for every customer.
