深圳某摄影摄像基地位于盐田区一工业园区内，原为一处闲置厂房改造而成。盐田地处亚热带沿海，气候湿润温暖，四季温差较小，夏季漫长且温湿度偏高，常年平均湿度约70%以上。这样的环境对室内拍摄场景的稳定性提出了较高要求，尤其在保证设备正常运行、避免镜头起雾、维持拍摄人员与模特舒适体感等方面，通风降温成为关键环节。

摄影摄像行业不仅是文化创意产业的重要组成，更是现代视觉传播、电商展示、广告制作及影视内容生产的核心基础设施。通过影像记录与创作，该行业助力企业品牌塑造、推动社会信息可视化传播，在经济、文化、教育等领域发挥着不可替代的作用。因此，为其提供稳定、专业的室内环境控制，直接关系到内容产出质量与创作效率。

该基地由大型彩钢棚结构厂房改建而成，总面积约3000平方米，层高达18米。内部设有多处风格各异的拍摄区，面积从百余平方米到近五百平方米不等。由于摄影棚采用轻质装修材料，承重能力有限，所有实装区域高度均控制在10米以下，导致10米至18米之间形成大面积挑空。这种结构对空调系统的冷量分布与气流组织构成了严峻挑战，容易造成能源浪费与温度不均。

瑞峰环保制冷方案团队综合考虑多项关键因素，包括：

1、地理气候环境：针对深圳高温高湿特点，注重除湿与降温并重；

2、建筑结构特性：结合挑高空间与轻质隔断布局，合理规划气流路径；

3、使用功能需求：确保拍摄区域不受设备视觉干扰、运行噪音低；

4、运维便捷性与节能要求：便于控制、维护，并实现自动化管理。

经周密分析，最终确定采用数十台大功率吊挂式射流省电智能控制型工业空调组合方案：

1、大功率输出：迅速应对大面积、高挑空带来的冷量需求，实现快速降温；

2、吊挂式安装：设备置于10米左右高度，有效避开取景范围，确保拍摄画面纯净；

3、射流送风技术：实现远距离定向送风，促进空间内空气循环，消除温度分层；

4、智能控制系统：支持远程启停、人员感应与分区分控，做到“人來开机、人走关机”，显著提升能效，降低运行成本。

项目完工后，摄影基地内部实现均匀、稳定的温湿度环境，拍摄区域温差控制在±1℃以内，且设备运行安静、无视觉遮挡，获得业主方的高度认可。基地负责人表示，该空调系统不仅提升了拍摄效率与人员舒适度，更在长期使用中展现出显著的节能效果，为高品质影像创作提供了可靠的环境保障。

此次工程虽是针对摄影摄像基地的特殊需求而设计，但其解决方案同样适用于其他具有高大空间、轻质结构或需隐蔽安装设备的场所，如：

1、文体场馆：体育馆、剧院、展览中心等；

2、工业车间：物流仓库、装配大厅、高端制造车间；

3、商业空间：大型卖场、批发市场、多功能厅等。

瑞峰环保制冷始终致力于为各类复杂空间提供专业化、定制化的通风降温解决方案，以技术实力与匠心服务，助力客户实现环境优化与可持续运营。

A photography and videography base in Shenzhen is located in an industrial park in Yantian District, which was originally transformed from an idle factory building. Yantian is located along the subtropical coast, with a humid and warm climate with small temperature differences throughout the year. The summer is long and the temperature and humidity are high, with an average humidity of over 70% throughout the year. This environment places high demands on the stability of indoor shooting scenes, especially in ensuring the normal operation of equipment, avoiding lens fogging, and maintaining the comfort of shooting personnel and models. Ventilation and cooling have become key links.

The photography and videography industry is not only an important component of cultural and creative industries, but also a core infrastructure for modern visual communication, e-commerce display, advertising production, and film and television content production. Through image recording and creation, this industry helps shape corporate brands and promotes the visual dissemination of social information, playing an irreplaceable role in fields such as economy, culture, and education. Therefore, providing stable and professional indoor environment control directly affects the quality of content output and creative efficiency.

The base was renovated from a large color steel shed structure factory, with a total area of about 3000 square meters and a height of 18 meters. There are multiple shooting areas with different styles inside, ranging in size from over 100 square meters to nearly 500 square meters. Due to the use of lightweight decoration materials in the studio, the load-bearing capacity is limited, and the height of all installation areas is controlled below 10 meters, resulting in a large area of overhang between 10 meters and 18 meters. This structure poses a serious challenge to the cooling capacity distribution and airflow organization of the air conditioning system, which can easily lead to energy waste and uneven temperature.

The Ruifeng Environmental Protection Refrigeration Solution Team has comprehensively considered multiple key factors, including:

1. Geographical climate environment: In response to the high temperature and humidity characteristics of Shenzhen, emphasis is placed on both dehumidification and cooling;

2. Architectural structural characteristics: Combining high rise space and lightweight partition layout, reasonably planning airflow paths;

3. Functional requirements: Ensure that the shooting area is not affected by device visual interference and has low operating noise;

4. Convenient operation and energy-saving requirements: easy to control, maintain, and achieve automated management.

After careful analysis, it was finally decided to adopt dozens of high-power hanging jet energy-saving intelligent control industrial air conditioning combination schemes:

1. High power output: Quickly respond to the cooling demand caused by large areas and high ceilings, achieving rapid cooling;

2. Hanging installation: The equipment is placed at a height of about 10 meters, effectively avoiding the shooting range and ensuring the purity of the captured image;

3. Jet air supply technology: achieving long-distance directional air supply, promoting air circulation in the space, and eliminating temperature stratification;

4. Intelligent control system: supports remote start stop, personnel sensing, and zoning control, achieving "human on, human off", significantly improving energy efficiency and reducing operating costs.

After the completion of the project, a uniform and stable temperature and humidity environment will be achieved within the photography base. The temperature difference in the shooting area will be controlled within ± 1 ℃, and the equipment will operate quietly without visual obstruction, which has been highly recognized by the owner. The base manager stated that the air conditioning system not only improves shooting efficiency and personnel comfort, but also demonstrates significant energy-saving effects in long-term use, providing a reliable environmental guarantee for high-quality image creation.

Although this project is designed for the special needs of photography and videography bases, its solution is also applicable to other places with tall spaces, lightweight structures, or equipment that requires concealed installation, such as:

1. Sports venues: sports centers, theaters, exhibition centers, etc;

2. Industrial workshops: logistics warehouses, assembly halls, high-end manufacturing workshops;

3. Commercial space: large shopping malls, wholesale markets, multifunctional halls, etc.

Ruifeng Environmental Protection Refrigeration has always been committed to providing professional and customized ventilation and cooling solutions for various complex spaces. With technical strength and craftsmanship, it helps customers achieve environmental optimization and sustainable operation.
