This project is located in Shunde District, Foshan City, which belongs to a typical subtropical monsoon climate zone. It is warm and humid all year round, with long and hot summers. The average temperature can reach 28-33 ℃, with high humidity and a feeling of stuffiness. Under such climatic conditions, ventilation and cooling of indoor sports venues are particularly important. As an indoor sports venue for external operation, this basketball court not only provides a professional and comfortable sports environment for surrounding residents, but also carries important social significance in promoting national fitness and promoting the development of community sports culture.

The main structure of the venue is made of color steel, and the walls are made of brick materials. For safety and energy conservation considerations, there are no large glass windows on the walls, and the overall airtightness is good; The roof is made of color steel tiles with insulation layer, effectively blocking sunlight and heat radiation. The total area of the venue is nearly 5000 square meters, with a height of over 15 meters. Inside, there are 2 standard basketball courts (including a small number of spectator seats, which can be used for competitions) and 4 non-standard basketball courts (mainly used for training), as well as rest areas. There is a physical partition between the two areas, forming independent functional zones.

The Ruifeng technical team has comprehensively considered multiple factors such as climate characteristics, spatial structure, usage scenarios, and operating costs, adhering to the design principle of "functional matching and optimal benefits", and has developed differentiated solutions for different regions:

The competition area has high requirements for environmental comfort and is equipped with audience seats, so dozens of wall mounted intelligent jet energy-saving industrial air conditioners are used. Although the initial investment of this plan is relatively high, it has precise temperature control capability, which can stably maintain the set temperature and ensure a comfortable and pleasant competition environment. Wall mounted installation saves ground space and prevents equipment from being impacted; Long distance jet air supply solves the problem of temperature difference in tall spaces; The intelligent start stop system automatically operates based on the flow of people, achieving a balance between energy conservation and comfort.

The main demands of the training area are ventilation, cooling, and cost control. Therefore, dozens of intelligent control air coolers (environmentally friendly air conditioners) installed on the exterior walls are selected to achieve high-level air supply through pipelines. Although the device does not have precise temperature control function, it can effectively reduce the perceived temperature by relying on the principles of high air volume ventilation and evaporative cooling. Moreover, the initial investment and operating costs are significantly lower than those of the air conditioning system, which greatly saves electricity expenses for the owner. High installation also ensures equipment safety and the complete utilization of site space.

The collaborative operation of the two systems not only meets the high standard requirements for precise temperature control in the competition area, but also achieves economical and efficient ventilation and cooling in the training area, creating an overall venue environment with reasonable zoning, energy-saving practicality, and comfortable experience. After the project was put into use, the expected results were achieved in different areas of the venue, and the operating costs were effectively controlled, receiving unanimous praise from the owners.

Engineering value extension:

This project vividly embodies Ruifeng Company's design philosophy of "adapting to local conditions and customizing according to needs". We deeply understand the characteristics of different devices - precise temperature control of air conditioning systems, suitable for areas with strict environmental requirements; Air coolers are known for their cost-effectiveness and are suitable for large-scale ventilation and cooling scenarios. In various high-rise spaces such as sports halls, industrial plants, logistics centers, commercial halls, etc., we are able to flexibly configure equipment combinations based on the actual functions and budgets of each area, providing customers with complete solutions that balance effectiveness, cost, and long-term operational benefits.
