一、项目概况

佛山直饮水机厂位于珠三角核心工业区，属亚热带季风气候，夏季炎热潮湿，最高气温可达35℃以上，湿度常高于80%；冬季温和，但昼夜温差明显，全年均需兼顾降温与通风需求。该厂房为12层钢筋混凝土结构标准厂房，外立面设有大面积采光玻璃窗，车间位于第5层，受西晒与室内设备散热双重影响，温控挑战显著。因建筑结构限制，空调外机仅能采用侧墙安装方式，进一步增加了系统设计难度。

二、定制化方案设计

瑞峰环保制冷技术团队综合考虑多重关键因素，量身打造高效节能的通风降温方案：

1、环境与建筑分析：佛山地区常年高湿高热，车间因玻璃窗占比较高，受太阳辐射增温明显；但厂房结构密闭性良好，适合采用内循环气流组织方案，减少外部湿热空气侵入，提升空调能效。

2、空间与生产特点：车间为直饮水机组装线，作业区域集中，设备密集，地面空间受限。因此选用吊挂式管道机型，不占用生产用地，同时利用管道灵活布置实现定点送风，精准覆盖人员固定工位，提升体感舒适度。

3、外机适配方案：针对中层楼层外机安装条件，采用侧墙加固悬挂工艺，结合防震支架与引流风罩，确保室外机高效散热，避免气流短路，保障系统长期稳定运行。

经综合评估，最终选用大功率管道式省电工业空调系统，融合蒸发冷却与机械制冷双模式，可根据季节与温度自动切换，大幅降低能耗。

三、安装实施与成果

项目团队严格执行标准化安装流程，管道布局沿车间顶部合理敷设，送风口精准对应工位线，室外机安装牢固并做防水防噪处理。系统投入使用后，车间温度稳定维持在26±2℃，湿度控制在60%以下，完全符合设计要求。业主反馈：不仅作业环境显著改善，且设备运行噪音低、能耗较传统空调降低约40%，真正实现了高效节能与舒适生产的平衡。

四、项目启示与专业延伸

本次直饮水机厂车间工程，虽是高层厂房的典型应用，却充分展现了瑞峰在复杂结构建筑中的空调方案解决能力。我们已具备成熟的技术经验，可灵活应对各类高空、侧装、管道隐蔽安装等特殊场景，适用于电子装配、食品包装、精密仪器等多行业的高层厂房、研发中心或仓储空间。瑞峰以专业设计、可靠安装与能效优化，持续为各类企业提供通风降温一体化解决方案，助力绿色生产。

1、 Project Overview

Foshan Direct Drinking Water Machine Factory is located in the core industrial area of the Pearl River Delta, with a subtropical monsoon climate. The summer is hot and humid, with the highest temperature reaching over 35 ℃ and humidity often exceeding 80%; Winter is mild, but there is a significant temperature difference between day and night, requiring a balance between cooling and ventilation throughout the year. The factory building is a 12 story reinforced concrete structure standard factory building, with a large area of daylighting glass windows on the exterior facade. The workshop is located on the 5th floor and is significantly challenged by temperature control due to the dual effects of western sunlight and indoor equipment heat dissipation. Due to the limitations of the building structure, the air conditioning outdoor unit can only be installed on the side wall, further increasing the difficulty of system design.

2、 Customized solution design

The Ruifeng Environmental Protection Refrigeration Technology Team has comprehensively considered multiple key factors and tailored an efficient and energy-saving ventilation and cooling solution:

(1). Environmental and Architectural Analysis: The Foshan area experiences high humidity and heat throughout the year. Due to the high proportion of glass windows in the workshops, there is a significant increase in temperature caused by solar radiation; But the factory structure has good airtightness and is suitable for adopting an internal circulation airflow organization scheme to reduce the intrusion of external humid and hot air and improve the energy efficiency of air conditioning.

(2). Space and production characteristics: The workshop is equipped with direct drinking water units, with a centralized work area, dense equipment, and limited ground space. Therefore, the hanging pipeline model is selected, which does not occupy production land, and utilizes flexible pipeline layout to achieve fixed-point air supply, accurately covering personnel fixed workstations and improving physical comfort.

(3). External unit adaptation plan: Based on the installation conditions of the external unit on the middle floor, the side wall reinforcement suspension technology is adopted, combined with shock-absorbing brackets and drainage hoods, to ensure efficient heat dissipation of the outdoor unit, avoid airflow short circuits, and ensure long-term stable operation of the system.

After comprehensive evaluation, a high-power pipeline energy-saving industrial air conditioning system was ultimately selected, which integrates evaporative cooling and mechanical cooling dual modes, and can automatically switch according to season and temperature, significantly reducing energy consumption.

3、 Installation Implementation and Results

The project team strictly follows the standardized installation process, and the pipeline layout is reasonably laid along the top of the workshop. The air supply outlet accurately corresponds to the workstation line, and the outdoor unit is firmly installed and treated with waterproofing and noise prevention. After the system was put into use, the workshop temperature remained stable at 26 ± 2 ℃ and the humidity was controlled below 60%, fully meeting the design requirements. Owner feedback: Not only has the working environment significantly improved, but the equipment also operates with low noise and reduces energy consumption by about 40% compared to traditional air conditioning, truly achieving a balance between high efficiency, energy conservation, and comfortable production.

4、 Project insights and professional extensions

The workshop project of the direct water dispenser factory, although a typical application of high-rise buildings, fully demonstrates Ruifeng's ability to solve air conditioning solutions in complex structural buildings. We have mature technical experience and can flexibly respond to various special scenarios such as high-altitude, side installation, and concealed pipeline installation. It is suitable for high-rise factories, research and development centers, or storage spaces in multiple industries such as electronic assembly, food packaging, and precision instruments. Ruifeng, with professional design, reliable installation, and energy efficiency optimization, continues to provide integrated ventilation and cooling solutions for various enterprises, supporting green production.
